Printing
Print Method: Thermal
Print Resolution: 203dpi
Print Speed: Up to 80mm/s
-
Processor
32-bit Cortex-M3-ARM CPU
-
Connectivity
Bluetooth | Type C
-
Memory
2MB RAM + 8MB Flash
-
Sensor
Out of Paper Sensor, Open Cover Sensor, Gap Sensor, Black Mark Sensor
-
Font Size
ASCII Font A: 12*24
ASC Font B: 9*17
Chinese Characters: 24*24
-
Font Type
GBK (Simplified Chinese), BIG5 (Traditional Chinese), KSC5601 (Korean), UTF-8 (Vector Font)
-
Bar Code
1D: EAN128, CODE128, CODE25, CODE39, CODE93, EAN13, EAN13+2, EAN13-5, CODABAR, POST, UPCA, UPCA+2, UPCA+5, UPCE+2, UPCE+5, PLESSY, ITF14, EAN14
2D: QR code, DataMatrix
-
Paper Size
Paper Width: 30-80mm
Paper Thickness: 0.05-0.12mm
Paper Roll Outer Diameter: ≤50mm
-
Paper Type
Receipt, Label
-
Print Command
TSPL, CPCL, ESC
-
Supporting Operating System
Android / iOS
-
Power Supply
5V/2A DC
-
Physical
115 x 104 x 60mm, 350g
-
Environment
Operating Temperature/Humidity: 0℃~50℃, 25%~85%RH
Storage Temperature/Humidity: -10℃~60℃, 10%~90%RH
-
Certification
CCC, CE
