Platform
k3568
Quad-core 64-bit Cortex -A55
The maximum frequencyis 2.0GHz
-
Home screen
15.6inch 1366*768
G+G multi-touch capacitive screen
Optional15.6 inch 1920*1080
-
Secondary screen
10.1 inch 800*1280
-
Memory
RAM:2G DDR4
Optional 4G DDR4 ROM
16G eMMC Optional 32G.64G eMMC
-
Button
On/off key *1
Reset key * 1
-
Trumpet
2W*1.stereo
-
Adapter
12V13A
-
Authentication
CCC
-
Material technology
Plastic iniection
molding+drying grain
-
Colour
white
-
Operating system
Android11.multilingual
Default Simplified Chinese
-
Network
BT:BT4.2
WiFi:2.4G single-f requency
wireless local area netyork
Ethernet: 10M/100M adaptive
-
Shipping software
Refer to customer requirements
Can cooperate with
deep customization system
-
Interface(external)
RJ45*1:Ethernet interface.
with indicator light on the interface seat
DC-N*1:power interface
RJ12*1: CashierInterface
Headphone hole *1
USB2.0*4: One of them supports OTG
-
Working environment
Temperature:0~45口
Humidity:5%-90%RH
(no condensation)
-
Storage environment
Temperature:-20 ~60口
Humidity:10%-90%RH
(ne condensaton)
-
Operating Environment
Operating Temperature: -10°C~50°C (14°F~122°F)
Relative Humidity: 5%~95% (Non-Condensing)
-
Storage Environment
Storage Temperature: -20°C~70°C (-4°F~158°F )
Relative Humidity: 5%~95% (Non-Condensing )
