OS
Asmart, Powered by Android 13
-
Processor
Cortex A53 Quad-Core, 2.0GHz + Secure Processor
Octa-Core, 4xA53 2.0GHz, 4xA53 1.5GHz + Secure Processor
-
Memory
2GB RAM + 8GB Flash
2GB RAM + 32GB Flash
Extended MicroSD Card Slot Up to 256GB
-
Card Readers
Magnetic Stripe | Chip & PlN | Contactless
-
Cameras
Front: 2MP Fixed Focus
Front: N/A
Top: 5MP Auto Focus, with Flashlight
Top: 2MP Fixed Focus
Top: 13MP Auto Focus, with Flashlight
-
Scanner
Top: 1D/2D professional scanner
-
Displays
Main Display: 6.745" IPS HD+, 720 x 1600 Pixels
Multi-Point Capacitive Touch Screen
Customer Display: Dot-matrix LCD, 130 x 32 Pixels
-
Wireless Communication
2G/3G/4G
Wi-Fi (802.11a/b/g/n/ac), 2.4GHz & 5GHz
Bluetooth5.0
-
Battery
Removable Polymer Battery
7.6V/2500mAh/19Wh (Equal to 3.6V/5278mAh )
7.7V/3420mAh/26.3Wh (Equal to 3.6V/7315mAh )
-
Printer
Speed: 80mm/sec | Paper Roll Outer Diameter: 40mm | Paper width: 58mm
-
Card Slots
2 Micro SIM + 2 Mini SAM + 1 Micro SD
eSIM + 1 Micro SIM + 2 Mini SAM + 1 Micro SD
-
Positioning
GPS | GLONASS | BEIDOU | GALILEO
-
Buttons
1 Power ON/OFF，1 Function
-
Fiscal
Fiscal Module
-
Audio
1 Speaker
1 Microphone
-
Ports
1 USB Type-C OTG | 5 PIN POGO PIN for Base
1 USB Type-C OTG | 4 PIN POGO PIN for Magnetic Charging
-
Adapter
Input: 100-240V AC, 50Hz/60Hz | Output: DC 5V/2A
-
Physical
192.5 x 81 x 57mm, 430g (including 2500mAh battery)
-
Operating Environment
Operating Temperature: 0°C~50°C (32°F~122°F)
Relative Humidity: 5%~95% (Non-Condensing)
-
Storage Environment
Storage Temperature: -20°C~60°C (-4°F~140°F )
Relative Humidity: 5%~95% (Non-Condensing )
-
Accessories
Charging Base
Multifunction Base
Magnetic Charging
-
Certifications
PCI PTS 6.x | EMV L1 & L2 | EMV CL1 | Visa PayWave | MasterCard PayPass | Unionpay Quickpass | American Express | Discover D-PAS | JCB J/Speedy | Anatel | ABECS | MasterCard TQM | CE | RoHS
